Electrostatic dissipative PEKK-based thermoplastic
Antero 840CN03 is a high-performance PEKK-based FDM thermoplastic with strong mechanical properties along with exceptional material properties, such as electro-static dissipation, temperature resistance, chemical resistance, exceptional wear properties, and ultra-low outgassing.
This makes it ideal for low-volume, highly-customized production parts and functional prototypes that need to withstand more intemperate conditions.
Antero 840CN03’s primary advantages over other Stratasys high-performance materials – such as ULTEM 9085 resin, ULTEM 1010 resin and PPSF – are its ESD, high chemical resistance, and low outgassing properties.
- Antero 840CN03 is currently available on the Stratasys F900 with a 0.254 mm slice height.
- It uses SUP8000B as a breakaway support system, similar to other Stratasys high- temperature material offerings. This support material is easier to remove than the other break away support systems.
- Antero 840CN03 requires the hardened head upgrade and utilizes a custom T20D tip for the model material, and the standard T16 tip for the support material.
